Chongqing TOP Oil Purifier Co., Ltd. is one of the most reliable manufacturers and suppliers of cooking oil recycling equipment in China, also supports customized service. Please feel free to buy advanced cooking oil recycling equipment made in China here from our factory.
Application
COP Series Cooking Oil Recycling Equipment
The COP series cooking oil recycling equipment can be used to recycle and process used cooking oil, removing water, gas, and impurities. It is mainly used for purifying used cooking oil, vegetable oil, edible oil, rape oil, sesame oil, peanut oil, coconut oil, beam oil, kitchen oil, bio-diesel oil, plant oil, wood oil etc. The cooking oil recycling equipment can effectively restore the quality of the original oil. The purified cooking oil can be used as a raw material for biodiesel or as a raw material for soap making.
To Meet Customers' Special Needs, We Develop
- COP Carbon Steel Cooking Oil Recycling Equipment
- COP Stainless Steel Cooking Oil Recycling Equipment
- COP -A Fully Automatic Cooking Oil Recycling Equipment
- COP -W Enclosed Cooking Oil Recycling Equipment
- TYS -Ex Explosion-Proof Cooking Oil Recycling Equipment
Features
1. Available in carbon steel or stainless steel material depending on requirements.
2. Uses stainless steel filter elements for longer service life.
3. Employs a backwashing system for automatic cleaning.
4. Compatible with PL, BAS, TYR series machines, etc.
Technical Parameters
|
Item |
Unit |
COP-10 |
COP -20 |
COP -30 |
COP -50 |
COP -100 |
COP -150 |
COP-200 |
COP -300 |
|
|
Flow Rate |
L/min |
10 |
20 |
30 |
50 |
100 |
150 |
200 |
300 |
|
|
Vacuum Degree |
Mpa |
-0.06 ~ - 0.095 |
||||||||
|
Working Pressure |
Mpa |
≤ 0.4 |
||||||||
|
Temperature Range |
℃ |
0~100 |
||||||||
|
Power Supply |
380V/50HZ/3P 5 Wires (Can be customized) |
|||||||||
|
Working Noise |
dB(A) |
≤ 65~82 |
||||||||
|
MTBF |
H |
≥ 4000 |
||||||||
|
Continuous Working |
H |
≥150 |
||||||||
|
Heating Power |
KW |
12 |
18 |
21 |
36 |
40 |
45 |
72 |
80 |
|
|
Total Power |
KW |
15 |
21 |
25 |
40 |
45 |
52 |
82 |
90 |
|
|
Oil Outlet/Inlet Caliber |
mm |
Φ25 |
Φ25 |
Φ25 |
Φ32 |
Φ42 |
Φ50 |
Φ50 |
Φ60 |
|
|
Weight |
KG |
450 |
550 |
600 |
750 |
850 |
1000 |
1200 |
1500 |
|
|
Size |
L |
mm |
1500 |
1500 |
1500 |
1600 |
1750 |
1900 |
1900 |
2100 |
|
W |
mm |
1000 |
1050 |
1050 |
1150 |
1250 |
1600 |
1700 |
1700 |
|
|
H |
mm |
1200 |
1600 |
1650 |
1700 |
1800 |
1950 |
2000 |
2100 |
|
|
Index After Filtering |
Moisture Content |
PPM |
≤ 100 |
|||||||
|
Gas Content |
% |
0.2 |
||||||||
|
Impurity Size |
μm |
≤5 (Can be customized) |
||||||||
|
Demulsification Value |
(Fresh oil)≤15min, (Oil in operation)≤30min |
|||||||||
|
Cleanliness |
Degree |
≤ 6(NAS 1638) |
||||||||
