Chongqing TOP Oil Purifier Co., Ltd. is one of the most reliable manufacturers and suppliers of hydraulic oil processing in China, also supports customized service. Please feel free to buy advanced hydraulic oil processing made in China here from our factory.
The TYA-Ex Hydraulic Oil Processing unit removes moisture, acids and oxidation sludge from aged insulating oils by combining vacuum dehydration, degassing and adsorbent regeneration, and can be installed as a fixed oil-treatment station or moved to the transformer for on-site service.
Technical Parameters
|
Item |
Unit |
TYA-Ex-10 |
TYA-Ex-20 |
TYA-Ex-30 |
TYA-Ex-50 |
TYA-Ex -100 |
TYA-Ex-150 |
TYA-Ex -200 |
TYA-Ex -250 |
TYA-Ex-300 |
|
|
Flow Rate |
L/min |
10 |
20 |
30 |
50 |
100 |
150 |
200 |
250 |
300 |
|
|
Flow Rate |
L/H |
600 |
1200 |
1800 |
3000 |
6000 |
9000 |
12000 |
15000 |
18000 |
|
|
Working Vacuum |
Mpa |
-0.06 ~- 0.098 |
|||||||||
|
Working Pressure |
Mpa |
≤0.3 |
|||||||||
|
Temperature Range |
℃ |
0~100 |
|||||||||
|
Working Oil Temperature |
℃ |
45~65 |
|||||||||
|
Power Supply |
380V/50HZ/3Ph 5 wire (Customizable) |
||||||||||
|
Continuous Working Time |
H |
≥150 |
|||||||||
|
Working Noise |
dB (A) |
≤65 |
≤68 |
≤68 |
≤70 |
≤70 |
≤75 |
≤75 |
≤78 |
≤80 |
|
|
Electric Heating Power |
kW |
15 |
18 |
24 |
36 |
60 |
72 |
120 |
150 |
180 |
|
|
Total Electric Power |
kW |
17 |
20 |
26 |
39 |
65 |
79 |
128 |
180 |
192 |
|
|
Inlet/Outlet |
mm |
Ф25 |
Ф25 |
Ф25 |
Ф32 |
Ф42 |
Ф45 |
Ф50 |
Ф60 |
Ф63 |
|
|
Weight |
kg |
350 |
400 |
450 |
500 |
900 |
1300 |
1500 |
1800 |
2000 |
|
|
Size |
L |
mm |
1350 |
1400 |
1450 |
1500 |
1700 |
1800 |
2000 |
2100 |
2400 |
|
W |
mm |
950 |
1000 |
1050 |
1100 |
1150 |
1250 |
1400 |
1450 |
1550 |
|
|
H |
mm |
1650 |
1700 |
1750 |
1800 |
1800 |
2000 |
2200 |
2300 |
2400 |
|
|
Index After Filtration |
Moisture Content |
PPM |
≤50 |
||||||||
|
Gas Content |
% |
0.1 |
|||||||||
|
Impurity Size |
μm |
≤1 (Customizable) |
|||||||||
|
Cleanliness |
NAS 1638 |
≤6 |
|||||||||
Features
- An oil level control module keeps feed and discharge balanced during unattended runs. In a vacuum chamber handling hot oil, foam that reaches the pump can cause damage and interrupt the batch, so built-in anti-foam elements collapse foam before it leaves the vessel, protecting the vacuum pump and maintaining a steady dewatering rate.
- Sensors on level, temperature and vacuum are interlocked with the heater circuit, cutting power if any reading drifts outside the safe range, which eliminates dry heating and prevents oil from being pulled through to the vacuum pump.
- A single-button PLC start controls the heating ramp, vacuum pull-down and oil circulation, producing the same purification result every cycle without relying on operator judgement.
